Radiant quartz heater for immediate heating and cooling
Variable speed control system
Suitable for discharge drying
Manual operation of conveyor also possible during power cuts
Individual chamber can be controlled – optional
Suitable for garments/ cloth, bags, non oven bags, jute bags and cotton bags.
Suction blower is provided to suck the odour and smoke
| Model | CC255 | CC310 | CC415 |
| Machine Size | 9' X 3' X 4' | 14.5' X 3.5' X 4' | 21' X 5' X 4' |
| Power | 440V | 440V | 440V |
| Heater | 9 KW | 15 KW | 36 KW |
| Working Area | 750 X 1500mm (2.5' X 5') | 900 X 3000mm (3' X 10') | 1200 X 4500mm (4' X 15') |
| Temperature | 200°C | 200°C | 200°C |
| Operating Speed | 33F / min | 33F / min | 33F / min |
| Conveyor Drive | DC Motor with 180 V DC Drive | DC Motor with 180 V DC Drive | DC Motor with 180 V DC Drive |
| Blower | 230 V AC/ 30W | 230 V AC/ 30W | 230 V AC/ 30W |
