Micro control based digital temperature and timer control
Automatic double stroke operation and production monitoring
Can be used for collar, cuff, leather, shoes and upholstery items
Die cast heater bed with teflon coating is used for longer life
| Model | CF2002 | CF2030 | CF2224 | CF2430 |
| Platen Size | 400 x 500mm 16" X 20" | 500 x 750mm 20" X 30" | 550 X 600mm 22" X 24" | 600 x 750mm 24" X 30" |
| Power | 230V, 50HZ, 11 Amps | 230V, 50HZ, 15 Amps | 230V, 50HZ, 15 Amps | 230V, 50HZ, 17.5 Amps |
| Heater | 2.5 KW | 3.5 KW | 3.5 KW | 4 KW |
| Temperature | 220°C | 220°C | 220°C | 220°C |
| Timer | 0 to 99 sec | 0 to 99 sec | 0 to 99 sec | 0 to 99 sec |
| Air Pressure | 0 - 8 Bar | 0 - 8 Bar | 0 - 8 Bar | 0 - 8 Bar |
| Air Consumption / Min | 0.4 cfm at 8 Bar | 0.6 cfm at 8 Bar | 0.6 cfm at 8 Bar | 0.6 cfm at 8 Bar |
